  • CONCEALED FASTENER

    Concept Series

    Concept Series panels give an unparalleled performance with stand-off clips that provide a ventilation chamber and drain plane below the panel.

    Centria's rainscreens elevates single-skin metal panels to new levels of cost-efficient aesthetics, innovation and performance.

    • MANUFACTURER

      Centria

    • SHARE:

    Finishes

    Color has the power to energize, to make a statement, and to evoke an emotion.

    Key Features

    Common-lock joint

    These rainscreen panels can be integrated with each other in the
    Concept Series and Cascade panel systems.

    Vertical or Horizontal

    Install with an unbroken appearance adding to the
    product’s aesthetic versatility.

    Stand Off Clips

    Stand-off clips provide a ventilation cavity and
    drain plane behind the panel.

    Panel Profiles

    To produce unique and exciting projects, establish a distinctive, coherent design pattern with diverse shapes and sizes.

    Specifications

    CS-260, CS-220*, CS-210, CS-200*

    GALVANIZED1 (G90) STAINLESS STEEL1 (304) ALUMINUM1 (3003-H14) ZINC1 (PRE-WEATHERED)
    PANEL DEPTH 7/8” [22mm] 7/8” [22mm] 7/8” [22mm] 7/8” [22mm]
    PANEL COVERAGE 12” [305mm] 12” [305mm] 12” [305mm] 12” [305mm]
    GAGES (STANDARD) 20 [.91mm], 22 [.76mm] 20 [.91mm], 22 [.76mm] .040” [1.02mm], .050” [1.27mm] 1mm [.039”]

    CS-660, CS-630*, CS-623*, CS-620*, CS-613*, CS-612*, CS-610*



    GALVANIZED1 (G90) STAINLESS STEEL1 (304) ALUMINUM1 (3003-H14) ZINC1 (PRE-WEATHERED)
    PANEL DEPTH 7/8” [22mm] 7/8” [22mm] 7/8” [22mm] 7/8” [22mm]
    PANEL COVERAGE 16” [406mm] 16” [406mm] 16” [406mm] 16” [406mm]
    GAGES (STANDARD) 20 [.91mm], 22 [.76mm] 20 [.91mm], 22 [.76mm] .040” [1.02mm], .050” [1.27mm] 1mm [.039”]
